heaterSteam V2
UR*
ลักษณะทั่วไป
Only for the U.S. market
The new range of heaterSteam humidifiers with immersed heaters includes models from 2 to 80 kg/h of steam, and can operate with drinking or demineralized water. The use of demineralized water reduces maintenance virtually to zero. heaterSystem features exclusive technological solutions covered by a patent, such as the electric heaters included in cast aluminium alloy with a large exchange surface area, each with a temperature sensor inside. The temperature sensor has two functions: protection against over-heating, for maximum reliability over time, and detection of excessive deposit of limestone well in advance, to allow proper preventive maintenance.
The modulating control with solid state relays guarantees high precision in humidity control, making heater Steam the ideal solution even for the most demanding applications.
For each capacity there are two variants: base and full optional.
The full optional machines, compared to the base ones, have thermal insulation around the boiler for maximum energy saving, and the heating elements are coated with non-stick material to facilitate the detachment of limestone.
They also have a water temperature sensor that allows the useful pre-heating function, for a quick response to any humidification request.
All models feature an automatic system to measure the conductivity of the supply water which optimizes the management of drainage without requiring, in general, the analysis of water during installation. This function also means energy saving and reduction of maintenance.-
เพิ่ม
Only for the U.S. market
- precision ±1% U.R.
- the heating elements are embedded in light cast alloys for perfect heat distribution;
- the temperature sensors inserted in the heating elements prevent any over-heating;
- the heating elements, coated with non-stick material (mod. full optional) are very easy to clean;
- continuous modulation of production from 0 to 100% of the nominal capacity;
- Anti Foaming System to prevent the emission of droplets with the steam;
- modulating limit probe to avoid any condensation in the duct (model H);
- water pre-heating function (mod. full optional);
เอกสาร
Technical
-
Certificates
* Entries are ordered by date
รหัส คำอธิบาย ภาษา วันที่ * Release รหัส tuv_6 คำอธิบาย heaterSteam: TUV certification ภาษา GER วันที่ 27/06/2003 Release รหัส tuv_5 คำอธิบาย heaterSteam: TUV certification ภาษา ENG FRE GER ITA POR SPA วันที่ 27/06/2003 Release รหัส ETL_3 คำอธิบาย heaterSteam 20-30 kg/h: ETL certification ภาษา ENG FRE GER ITA POR SPA วันที่ 27/11/2002 Release รหัส ETL_2 คำอธิบาย heaterSteam 6-10 kg/h: ETL certification ภาษา ENG FRE GER ITA POR SPA วันที่ 27/11/2002 Release รหัส ETL_1. คำอธิบาย heaterSteam 2-4 kg/h: ETL certification ภาษา ENG FRE GER ITA POR SPA วันที่ 27/11/2002 Release -
Manuals
* Entries are ordered by date
รหัส คำอธิบาย ภาษา วันที่ * Release รหัส +0300080DE คำอธิบาย heaterSteam - UR Befeuchter mit elektrischen Heizelementen ภาษา GER วันที่ 05/02/2018 Release 1.4 รหัส +0300075FI คำอธิบาย heaterSteam - UR Vastustoiminen kostutin ภาษา FIN วันที่ 29/09/2015 Release 1.2 รหัส +0300075EN คำอธิบาย heaterSteam - UR Electric resistance humidifier ภาษา ENG วันที่ 29/09/2015 Release 1.2 รหัส +0300075ES คำอธิบาย heaterSteam - UR Humidifi cador por resistencias eléctricas ภาษา SPA วันที่ 29/09/2015 Release 1.2 รหัส +0300075PT คำอธิบาย heaterSteam - UR Humidifi cador de resistências elétricas ภาษา POR วันที่ 29/09/2015 Release 1.2 รหัส +0300075DE คำอธิบาย heaterSteam - UR Befeuchter mit elektrischen Heizelementen ภาษา GER วันที่ 29/09/2015 Release 1.2 รหัส +0300075FR คำอธิบาย heaterSteam - UR Humidificateur à résistances électriques ภาษา FRE วันที่ 29/09/2015 Release 1.2 รหัส +0300075IT คำอธิบาย heaterSteam - UR Umidificatore a resistenza elettriche ภาษา ITA วันที่ 29/09/2015 Release 1.2 รหัส +030220311 คำอธิบาย Humiset ภาษา ENG วันที่ 01/09/2014 Release 2.2 รหัส +030220310 คำอธิบาย humiSet Humidifier Programming Tool ภาษา ITA วันที่ 01/09/2014 Release 2.2 รหัส +030222014 คำอธิบาย heaterSteam - UR: Humidificador por resistencias eléctricas ภาษา SPA วันที่ 31/10/2012 Release 2.4 รหัส +030222013 คำอธิบาย heaterSteam - UR: Befeuchter mit elektrischen Heizelementen ภาษา GER วันที่ 31/10/2012 Release 2.4 รหัส +030222012 คำอธิบาย heaterSteam - UR: Humidificateur à résistances électriques ภาษา FRE วันที่ 31/10/2012 Release 2.4 รหัส +030222011 คำอธิบาย heaterSteam - UR: electrical heater humidifier ภาษา ENG วันที่ 31/10/2012 Release 2.4 รหัส +030222010 คำอธิบาย heaterSteam - UR:umidificatore a resistenze elettriche ภาษา ITA วันที่ 31/10/2012 Release 2.4
Commercial
-
Brochure
* Entries are ordered by date
รหัส คำอธิบาย ภาษา วันที่ * Release รหัส +3000109ZH คำอธิบาย heaterSteam 电热型加湿器 前所未有的精密控制与高可靠性 ภาษา CHI วันที่ 20/06/2018 Release 2.0 รหัส +3000056NL คำอธิบาย heaterSteam: de beste precisie en betrouwbaarheid ภาษา DUT วันที่ 01/03/2014 Release 2.0 รหัส +3000056IT คำอธิบาย heaterSteam: la migliore precisione e affidabilità ภาษา ITA วันที่ 01/03/2014 Release 2.0 รหัส +3000056ES คำอธิบาย heaterSteam: la máxima precisión y fiabilidad ภาษา SPA วันที่ 01/03/2014 Release 2.0 รหัส +3000056EN คำอธิบาย heaterSteam: the best precision and reliability ภาษา ENG วันที่ 01/03/2014 Release 2.0 รหัส +3000056DE คำอธิบาย heaterSteam: höchste Präzision und Zuverlässigkeit ภาษา GER วันที่ 01/03/2014 Release 2.0 รหัส +3000056FR คำอธิบาย heaterSteam:précision et fiabilité optimales ภาษา FRE วันที่ 01/03/2014 Release 2.0 รหัส +3000056ZH คำอธิบาย heaterSteam 精确的、可靠的加湿方案 适用于各种类型应用 ภาษา CHI วันที่ 03/01/2014 Release 2.0
